>1235 aluminium foil is the aluminium foil of aluminium content not less than 99.35%,Haomei Aluminum can process 1235-O and 1235-H18 aluminum foils with a thickness of 0.016-0.2mm. This product is widely used in cables, tape foils, and lithium batteries because of its excellent anti-rust properties, formability, and fusion properties. Cover with aluminum foil.
Rolled in Alloy 1235 with 99.35% minimum aluminum content, our foil slit edges are very clean, resulting in a consistent unwind with minimal breaks.
Alloy | 1235 |
Temper | O,H18 |
Thickness(mm) | 0.016-0.2 |
Width(mm) | 100-1700 |
Length(mm) | c |
Alloy | Product Type | Temper | Thickness (mm) | Tensile Strength (Mpa) | Elongation(%) A100mm |
1235 | Food and Household Foil | O | 0.01-0.024 | 40-100 | ≥1 |
0.025-0.04 | 45-100 | ≥2 | |||
0.041-0.07 | 45-100 | ≥4 | |||
H18 | 0.01-0.07 | ≥135 | – | ||
aluminium foil for capacitor | H18 | 0.02-0.05 | ≥135 | – | |
aluminium foil for cable | O | 0.01-0.024 | 40-100 | ≥1 | |
0.025-0.04 | 45-100 | ≥2 | |||
0.041-0.07 | 45-100 | ≥4 | |||
aluminium foil for adhesive tape | O | 0.012-0.04 | 50-90 | ≥1 | |
H18 | ≥135 | – | |||
O | 0.03-0.07 | 60-100 | ≥2 |
